Tyan Tank Barebone System B5380T26V8HR TA26 B5380T26V8HR

The Tank TA26 (B5380) provides high-density storage for departmental/NAS 2U rackmount applications. Supports dual Intel Xeon 5000/5100 series processors, (8) FBDIMM memory sockets, PCI-E and PCI-X expansion slots, (6) SATA-II hot-swap drive bays, built-in 650W redundant 1+1 PFC power supply and much more.

Product Type	Barebone System
Product Series	TA26
Brand Name	Tyan
Manufacturer	Tyan Computer Corp
Product Model	TA26 B5380T26V8HR
Product Name	Tank TA26 B5380T26V8HR Barebone System
Product Line	Tank
Manufacturer Part Number	B5380T26V8HR
Manufacturer Website Address	http://www.tyan.com
Number of External 5.25" Bays	1
Number of Total Expansion Bays	9
Number of 3.5" Bays	8
Number of Total Expansion Slots	5
Number of PCI Express x8 Slots	1
Number of PCI Express x16 Slots	2
Chipset Manufacturer	Intel
Chipset Model	5000X
Number of Processors Supported	2
Processor Socket	Socket J LGA-771
Processor Supported	Xeon
Graphics Controller Manufacturer	ATI
Graphics Controller Model	ES1000
Graphics Memory Capacity	32 MB
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1.20 kW
Number of Total Memory Slots	8
Memory Standard	DDR2-667/PC2-5300
Memory Technology	DDR2 SDRAM
Maximum Memory	16 GB
RAID Supported	Yes
Controller Type	Serial ATA/300
Ethernet Technology	Gigabit Ethernet
Total Number of USB Ports	8
Height	3.5"
Width	17"
Depth	26"
Rack Height	2U
Form Factor	Rack-mountable
Limited Warranty	3 Year
