Tyan Barebone System B7015F77V4R-N429 FT77B7015

144 GB DDR3 SDRAM DDR3-1333/PC3-10600 Maximum RAM Support - Serial ATA/300 RAID Supported Controller - ASPEED AST2050 Integrated - 4 x Total Bays - 4 2.5" Bay(s) - 13 x Total Expansion Slots - Processor Support (Xeon) - 3 x 2.40 kW

Product Type	Barebone System
Product Series	FT77
Brand Name	Tyan
Manufacturer	Tyan Computer Corp
Product Model	FT77B7015
Product Name	FT77B7015 Barebone System
Manufacturer Part Number	B7015F77V4R-N429
Manufacturer Website Address	http://www.tyan.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	FT77B7015 Barebone System 4 x NV M2090 cards 1 x TYAN Installation CD 1 x User's Manual 16 x Power Cables
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	5520
Number of Processors Supported	2
Processor Socket	Socket B LGA-1366
Processor Supported	Xeon
Number of PCI Slots	1
Number of Internal 2.5" Bays	4
Number of Total Expansion Bays	4
Number of Total Expansion Slots	13
Number of PCI Express x16 Slots	10
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2050
Number of Power Supplies Installed	3
Maximum Power Supply Wattage	2.40 kW
Input Voltage	110 V AC220 V AC
Number of Total Memory Slots	18
Memory Standard	DDR3-1333/PC3-10600
Memory Technology	DDR3 SDRAM
Maximum Memory	144 GB
RAID Supported	Yes
Controller Type	Serial ATA/300
Ethernet Technology	Gigabit Ethernet
Total Number of USB Ports	2
Height	6.9"
Width	17.2"
Depth	31.3"
Color	Black
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	63.93 lb
Limited Warranty	3 Year
