Tyan Tomcat HX Server Motherboard S8050GM4NE-2T S8050

EPYC Processor Supported - 2 TB DDR5 SDRAM Maximum RAM - DIMM, RDIMM - 8 x Memory Slots - Gigabit Ethernet - 12 x SATA Interfaces

VGA	Yes
Number of Network (RJ-45) Ports	5
Product Type	Server Motherboard
Manufacturer Part Number	S8050GM4NE-2T
Manufacturer Website Address	http://www.tyan.com
Packaged Quantity	1
Manufacturer	Tyan Computer Corp
Product Model	S8050
Product Name	Tomcat HX S8050 Server Motherboard
Brand Name	Tyan
Number of PCI Express x16 Slots	5
PCI Express Standard	PCI Express 5.0
Total Number of PCI Express Slots	5
Total Number of Expansion Slots	5
Maximum Memory Supported	2 TB
Memory Technology	DDR5 SDRAM
Number of Memory Slots	8
Memory Form Factor	DIMM RDIMM
Memory Speed Supported	4800 MHz 4000 MHz
Package Contents	Tomcat HX S8050 Server Motherboard 1 x Quick Installation Guide 1 x I/O Shield 2 x SATA signal cables
Environmental Compliance	China Restriction of Hazardous Substances (China RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) Restriction of Hazardous Substances (RoHS) 6
Gigabit Ethernet	Yes
10Gigabit Ethernet	Yes
Form Factor	SSI CEB
Width	12"
Depth	10.5"
Processor Supported	EPYC
Total Processor Supported	1
Processor Socket	Socket SP5 LGA-6096
Chipset Manufacturer	AMD
Processor Generation Supported	4th Gen
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2600
Onboard Video	CPU Dependent Video
Controller Type	Serial ATA/600
Number of SATA Interfaces	12
Number of M.2 Interfaces	2
