Tyan Tomcat CX Server Motherboard S8056GME S8056

EPYC Processor Supported - 3 TB DDR5 SDRAM Maximum RAM - DIMM, RDIMM - 24 x Memory Slots - Gigabit Ethernet - 16 x SATA Interfaces

VGA	Yes
Number of Network (RJ-45) Ports	1
Product Type	Server Motherboard
Manufacturer Part Number	S8056GME
Manufacturer Website Address	http://www.tyan.com
Packaged Quantity	1
Manufacturer	Tyan Computer Corp
Product Model	S8056
Product Name	Tomcat CX S8056 Server Motherboard
Product Line	Tomcat CX
Brand Name	Tyan
Number of PCI Express x16 Slots	1
PCI Express Standard	PCI Express 5.0
Total Number of PCI Express Slots	3
Total Number of Expansion Slots	3
Number of PCI Express x24 Slots	1
Maximum Memory Supported	3 TB
Memory Technology	DDR5 SDRAM
Number of Memory Slots	24
Memory Form Factor	DIMM RDIMM
Memory Speed Supported	4800 MHz 4000 MHz
Package Contents	Tomcat CX S8056 Server Motherboard 1 x Quick Installation Guide 2 x SATA signal cables 1 x OCP 3.0 Slide Rail / (1) M.2 Card Latch
Environmental Compliance	China Restriction of Hazardous Substances (China RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) Restriction of Hazardous Substances (RoHS) 6
Gigabit Ethernet	Yes
Form Factor	Proprietary Form Factor
Width	14.2"
Depth	12.2"
Processor Supported	EPYC
Total Processor Supported	1
Processor Socket	Socket SP5 LGA-6096
Chipset Manufacturer	AMD
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2600
Onboard Video	CPU Dependent Video
Controller Type	Serial ATA/600
Number of SATA Interfaces	16
Total Number of Onboard USB Ports	2
Number of M.2 Interfaces	2
