Tycon Power POE 5 Port Switch TP-SW5G-NC

Free Shipping
Tycon Power POE 5 Port Switch TP-SW5G-NC
Price $170.43
Manufacturer: Tycon Power
Mfg Number: TP-SW5G-NC
SKU:
Condition: New
UPC: 611102303328
Accessories
Description
Tycon Power Systems TP-SW5G-NC: Universal Voltage 10/100/1000MB PoE Switch. Switch accepts a voltage from 12-56VDC and outputs the same voltage to 4 PoE ports. 1A per port. The unit supplies PoE power to the remote device on Ethernet pins 4,5(V+) and 7,8(V-). The Ethernet spec supports distances up to 100m (328 feet) between the PoE switch and the remote device. The switch accepts DC power from any power supply. The PoE output voltage equals the DC voltage of the power supply used from 12V to 56VDC. The switch also includes an unpoowered uplink port. The switch can be powered through this uplink port with 12V to 56VDC so it can be used as a repeater/extender in a remote location.
Specifications
Product TypeEthernet Switch
Product SeriesTP-SW5
Brand NameTycon Power
ManufacturerTycon Power Systems
Product ModelTP-SW5G-NC
Product NamePOE 5 Port Switch
Manufacturer Part NumberTP-SW5G-NC
Manufacturer Website Addresshttp://www.tyconpower.com
ManageableYes
Redundant Power SupplyNo
Power SourceAC Adapter
Ethernet TechnologyGigabit Ethernet
Media Type SupportedTwisted Pair
Network Technology10/100/1000Base-TX
ModularNo
Uplink PortYes
Stack PortNo
Total Number of Network Ports5
Port/Expansion Slot Details5 x Gigabit Ethernet Network
Height1.6"
Width6.3"
Depth4.6"
Form FactorRail-mountableDesktop
Weight (Approximate)1.10 lb
Package Contents
  • POE 5 Port Switch
  • DIN Rail Mountable Kit
Limited Warranty2 Year
Layer Supported2
