Valcom Speaker VSA-1020C

The Valcom VSA-1020C amplified speaker assembly has been designed specifically for use with the Simplex 5100 Series Communications System when multiple transducers are required for specific areas or zones. The Valcom VSA-1020C incorporates an 8" cone speaker, an integral amplifier and a volume control in a design that allows Valcom technology to be used with any applicable baffle design. The amplifier requires a line level signal input and 24 VDC to deliver its directly coupled 1-watt output to the cone assembly. Since the amplifier is mounted at the speaker a full 1-watt signal is generated even when dealing with long line runs.

Product Type	Speaker
Brand Name	Valcom
Manufacturer	Valcom, Inc
Product Model	VSA-1020C
Product Name	VSA-1020C Speaker
Manufacturer Part Number	VSA-1020C
Manufacturer Website Address	http://www.valcom.com
Minimum Frequency Response	70 Hz
Maximum Frequency Response	12 kHz
RMS Output Power	12 W
Impedance	10 Kilo Ohm
Signal to Noise Ratio (SNR)	-70 dB
Limited Warranty	1 Year
