Vivotek L2 Plus Managed Switch 20xGE SFP + 4xCombo GE + 4x1G/10G SFP+ AW-GTS-287A

Vivotek L2 Plus Managed Switch 20xGE SFP + 4xCombo GE + 4x1G/10G SFP+ AW-GTS-287A
Price $1,488.64
Manufacturer: Vivotek
Mfg Number: AW-GTS-287A
Condition: New
VIVOTEK's AW-GTS-287A L2 Plus Managed Switch is a next-generation Fiber Switch offering a full suite of L2 Plus features and additional 1G/10G SFP+ uplink connections. The AW-GTS-287A L2 Plus includes advanced L3 features such as Static Route that delivers a better cost-performance ratio and a lower total cost of ownership in both Enterprise networks and backbone via fiber or copper connections.With high Gigabit port densities and Gigabit SFP, 1G/10G SFP+ support, the GTS-287A switch can act as either a departmental access layer or as an aggregation switch to form a multilevel network. Service providers can take advantage of the high SFP density to structure the aggregation of Fiber to the Building (FTTB) networks that can be extended to subscribers' sites.The AW-GTS-287A can be programmed for a number of advanced switch management functions, such as dynamic port link aggregation, Q-in-Q VLAN, Multiple Spanning Tree Protocol (MSTP), Layer 2/4 QoS, bandwidth control, IGMP/MLD snooping, GARP VLAN Registration Protocol (GVRP) and sFlow. Through link-aggregation of supporting ports, the AW-GTS-287A allows the operation of a high-speed trunk to combine with multiple ports. It enables a maximum of 14 trunk groups, with up to 16 ports in each group, and also supports connection fail-over.The AW-GTS-287A is also specially equipped with one 100~240V AC power supply unit and one 24~72V DC power supply unit to provide enhanced reliability and enable scalable redundant power supply installation. The continuous power system is designed to fulfill the specific demands of high tech facilities requiring the highest power integrity and stability.
Product Type Ethernet Switch
Brand Name Vivotek
Manufacturer Vivotek, Inc
Product Model AW-GTS-287A
Product Name L2 Plus Managed Switch 20xGE SFP + 4xCombo GE + 4x1G/10G SFP+
Manufacturer Part Number AW-GTS-287A
Manufacturer Website Address http://www.vivotek.com
Manageable Yes
Ethernet Technology Gigabit Ethernet 10 Gigabit Ethernet
Media Type Supported Optical Fiber Twisted Pair
Network Technology 1000Base-X 10GBase-X 10/100/1000Base-T
Number of Total Expansion Slots 28
Number of SFP Slots 24
Number of SFP+ Slots 4
Shared SFP Slot Yes
Expansion Slot Type SFP
Modular Yes
Uplink Port No
Stack Port No
Total Number of Network Ports 4
Port/Expansion Slot Details 24 x Gigabit Ethernet Expansion Slot 4 x Gigabit Ethernet Network 4 x 10 Gigabit Ethernet Expansion Slot
Redundant Power Supply Supported No
Power Source Power Supply
Height 1.7"
Width 17.4"
Depth 8.3"
Form Factor Rack-mountable
Weight (Approximate) 6.83 lb
Package Contents
  • L2 Plus Managed Switch 20xGE SFP + 4xCombo GE + 4x1G/10G SFP+
  • Power Cord
  • QIG
  • CD Manual
  • Rack Mount Kit
  • Console cable
Layer Supported 2
