APC Rack Side Air Distribution System ACF202BLK

Housing equipment with side to side airflow creates many challenges for IT and facility managers, particularly in regards to cooling. Because most enclosures are designed for a front to back airflow pattern, it is difficult to maintain ideal operating temperatures on side to side airflow equipment. The Rack Side Air Distribution Unit is a 2U rack mountable air distribution product for networking equipment or servers with side to side airflow. It pulls in conditioned air from the front of the rack and distributes it to the side air intake of the networking equipment.

Product Type	Airflow Cooling System
Brand Name	APC
Manufacturer	American Power Conversion Corp
Product Model	ACF202BLK
Product Name	ACF202BLK Rack Side Air Distribution System
Manufacturer Part Number	ACF202BLK
Manufacturer Website Address	http://www.apc.com
Package Contents	ACF202BLK Rack Side Air Distribution System Installation Guide User Manual
Height	3.4"
Width	17"
Depth	26.3"
Color	Black
Form Factor	Rack-mountable
Weight (Approximate)	32.08 lb
Input Voltage	230 V AC
Receptacle Type	IEC 60320 C14
Maximum Air Flow	260 CFM
Limited Warranty	2 Year
