APC Smart-UPS VT 20kVA Rack-mountable UPS SUVTRT20KF5B5S

APC Smart-UPS VT 20kVA Rack-mountable UPS SUVTRT20KF5B5S
Price $20,914.08
Manufacturer: APC
Mfg Number: SUVTRT20KF5B5S
SKU:
Condition: New
Accessories
Description
Over 10 million installed - now available in three-phase Smart-UPS VT SUVTRT20KF5B5S offers centralized three-phase power protection with the reliability of the award winning Smart-UPS family. Ideal for small data centers, large retail stores, regional offices, and dense power requirements. The rack mounted version maximizes valuable floor space by incorporating UPS, power distribution, and additional battery capacity in a single rack. Low cost of ownership is achieved through best-in-class efficiency and a reduction in rating of electrical infrastructure - wires, transformers, and generators due the soft start feature. The APC Network Management Card with temperature monitoring provides remote monitoring and management through a simple Web/SNMP interface and provides integration with InfraStruXure Manager. All these features make it the easiest UPS in its class to deploy, manage and maintain.
Specifications
Product TypeDual Conversion Online UPS
Product SeriesVT
Brand NameAPC
ManufacturerAmerican Power Conversion Corp
Product NameSmart-UPS VT 20kVA Rack-mountable UPS
Product LineSmart-UPS
Manufacturer Part NumberSUVTRT20KF5B5S
Manufacturer Website Addresshttp://www.apc.com
BatteriesValve-regulated Lead Acid (VRLA)
Height78.5"
Width23.6"
Depth42"
Form FactorRack-mountable
Weight (Approximate)2290 lb
Receptacles1 x Hard Wire 5-wire 3PH + N + G - Backup/Surge-protected
Plug/Connector TypeHard Wire 5-wire 3PH + N + G
Input Voltage Range208 V AC 3-phase Nominal177 V AC to 239 V AC Mains Operation
Load Capacity20 kVA/16 kW
Input Voltage110 V AC220 V AC
Output Voltage120 V AC Nominal208 V AC 3-phase Nominal
Network ManagementSNMP Manageable Included
Package Contents
  • Smart-UPS VT 20kVA Rack-mountable UPS
  • Installation Guide
  • Power modules ship installed
  • Smart UPS signalling RS-232 cable
  • Start up included
  • User Manual
  • Web/SNMP Management Card
Limited Warranty1 Year
