Black Box Gb ETH IND PoE MED CONV 10/100/1000Mbps COP 100/1000Mbps FBR SFP LGC5500A

Power PoE Devices The converter supports Power over Ethernet (PoE), so you can power remote devices, such as wireless access points, cameras and more, through standard twisted-pair cable. Designed for Harsh Conditions Black Box Industrial Media Converters are designed to perform in the toughest environments on earth. This converter features rigid IP-30 housing that makes it ideal for a range of industrial and outdoor applications. Easy to Mount Install this converter however you want. It can be wall mounted or placed on a DIN rail. Extend LAN Reach This media converter allows you to add fiber into your existing network infrastructure with ease. Fiber can extend network signals up to distances of 80 kilometers - much farther than the 100-meter limit of CATx cable. This media converter supports super-fast gigabit Ethernet that is certain to meet your business needs. Supports Link Fault Pass-Through This media converter has a link fault pass-through feature that simplifies troubleshooting. When one side of the link fails, the other side continues transmitting packets and waiting for a response from the disconnected side.

Network (RJ-45)	Yes
Number of PoE (RJ-45) Ports	1
Total Number of Ports	1
PoE Port Type	PSE
Product Type	Transceiver/Media Converter
Manufacturer Part Number	LGC5500A
Manufacturer Website Address	http://www.blackbox.com
Manufacturer	Black Box Corporation
Product Name	Gb ETH IND PoE MED CONV 10/100/1000Mbps COP 100/1000Mbps FBR SFP
Product Series	LGC5500
Brand Name	Black Box
Expansion Slot Type	SFP (mini-GBIC)
Number of Total Expansion Slots	1
Number of SFP Slots	1
Media Type Supported	Twisted Pair Optical Fiber
Country of Origin	Taiwan
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE
TAA Compliant	Yes
Network Technology	10/100/1000Base-TX 1000Base-X
Ethernet Technology	Gigabit Ethernet
Weight (Approximate)	9.60 oz
Form Factor	DIN Rail Mountable Panel-mountable Wall Mountable
Height	3.7"
Width	1.6"
Depth	2.8"
Limited Warranty	5 Year
