CyberPower Smart App Sinewave 2.2KVA Tower/Rack Convertible UPS PR2200RTXL2U

CyberPower Smart App Sinewave 2.2KVA Tower/Rack Convertible UPS PR2200RTXL2U
Price $1,301.40
Manufacturer: CyberPower
Mfg Number: PR2200RTXL2U
Condition: New
UPC: 649532620647
The PR2200RTXL2U is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower's Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment. The Smart App Sinewave PR2200RTXL2U improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR2200RTXL2U also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options. This model accepts the BP48VP2U02 Extended Battery Module (EBM) for expanded runtime during power outages and the RMCARD205 network management card for remote management and control via a standard web browser or network management system. With a $400,000 connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of the PR2200RTXL2U. More from the Manufacturer
Battery Chemistry Lead Acid
Battery Size 12V
Battery Capacity 9000 mAh
Number of Batteries 4
Backup/Run Time (Half Load) 10 Minute
Backup/Run Time (Full Load) 3.20 Minute
Battery Characteristics Sealed
Replaceable Battery Yes
DC System Voltage 12 V DC
Typical Battery Recharge Time 3 Hour
Status Indicators
  • LCD Display
LED Indicators:
  • Power on
  • Line mode
  • Battery mode
  • Fault
  • Night mode
  • Wiring Fault
Serial Port Yes
EPO Port Yes
USB (HID Compliant) Port Yes
Thermal Dissipation 34 W
Maximum Operating Temperature 104°F (40°C)
Maximum Operating Elevation 10000 ft
Maximum Storage Elevation 50000 ft
Operating Humidity 0% - 95%
Storage Relative Humidity 0% - 95%
Storage Temperature 5°F (-15°C) - 113°F (45°C)
Sound Emission (A-Weighted) 57.5 dB(A)
Product Type Line-interactive UPS
Manufacturer Part Number PR2200RTXL2U
Manufacturer Website Address http://www.cyberpowersystems.com
Manufacturer CyberPower Systems, Inc
Product Name Smart App Sinewave 2.2KVA Tower/Rack Convertible UPS
Product Series New Smart App Sinewave UPS
Brand Name CyberPower
Product Condition New
Network Management SNMP/HTTP Remote Monitoring
Alarm Battery Mode Overheat Over Charge Overload Low Battery
Country of Origin Philippines
Environmentally Friendly Yes
Environmental Certification RoHS GreenPower UPS
Energy Star Yes
Weight (Approximate) 79.60 lb
Form Factor Rack/Tower
Rack Height 2U
Height 3.4"
Width 17.1"
Depth 19.7"
Product Color Black
Input Voltage 120 V AC
Output Voltage 100 V AC 110 V AC 120 V AC
Load Capacity 2200 VA
Surge Energy Rating 2430 J
Waveform Type Sine Wave
Input Voltage Range 75 V AC - 149 V AC
Output Frequency 60 Hz
Input Frequency 63 Hz
Dataline Protection RJ-45
Overload Protection Yes
Plug/Connector Type NEMA L5-30P
Receptacle Type NEMA 5-20R
EMI/RFI Noise Filter Yes
AVR Range Boost +2% / Buck -1%
Energy Saving GreenPower UPS™ Bypass Technology
Number of Battery & Surge Outlets 8
Number of Critical Load Outlets 4
Transfer Time 4 ms
Receptacle Detail 8 x NEMA 5-20R
Limited Warranty 3 Year
