Dataram 4GB DDR3 SDRAM Memory Module DTM64429C

DTM64429C is a registered 512Mx72 memory module, which conforms to JEDEC's DDR3L-1600, PC3L-12800 standard. The assembly is a SingleRank, containing nine 512Mx8 DDR3 Samsung SDRAMs. One 2K-bit EEPROM is used for Serial Presence Detect and a combination register/PLL, with Address and Command Parity, is also used. Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology. A thermal sensor accurately monitors the DIMM module and can prevent exceeding the maximum operating temperature of 95C.

Product Type	RAM Module
Manufacturer Part Number	DTM64429C
Manufacturer Website Address	http://www.dataram.com
Manufacturer	Dataram Corporation
Product Name	4GB DDR3 SDRAM Memory Module
Brand Name	Dataram
Compatibility	Supermicro X9DA7 Motherboard
Environmentally Friendly	Yes
Environmental Certification	RoHS
Number of Pins	240-pin
Thickness	155.1 mil
Form Factor	DIMM
Length	5.3"
Width	1.2"
CAS Latency	CL11
Device Supported	Server
Error Checking	ECC
Number of Modules	1 x 4GB
Signal Processing	Registered
Memory Speed	1600 MHz
Memory Size	4 GB
Memory Technology	DDR3 SDRAM
Memory Standard	DDR3-1600/PC3L-12800
Memory Voltage	1.35 V
