Dataram 128GB DDR4 SDRAM Memory Module DTM68305-S

DTM68305-S is a load reduced 16Gx72memory module, which conforms toJEDEC's DDR4-2400, PC4-2400 standard.The assembly is Eight-Rank containing -thirty-six Samsung 8Gbx4 DDR4-2400 4HTSV SDRAMs. One 4K-bit EEPROM isused for Serial Presence Detect and aRegistering Clock Driver, with Address andCommand Parity, is also used as well asdata buffers to reduce the overall loadingon the data bus.Both output driver strength and inputtermination impedance are programmableto maintain signal integrity on the I/Osignals in a Fly-by topology. A thermalsensor accurately monitors the DIMMmodule and can prevent exceeding themaximum operating temperature of 95C.

Product Type	RAM Module
Manufacturer Part Number	DTM68305-S
Manufacturer Website Address	http://www.dataram.com
Manufacturer	Dataram Corporation
Product Name	128GB DDR4 SDRAM Memory Module
Brand Name	Dataram
Environmentally Friendly	Yes
Environmental Certification	RoHS
Number of Pins	288-pin
Thickness	156.7 mil
Form Factor	LRDIMM
Length	5.3"
Width	1.2"
CAS Latency	CL19
Error Checking	ECC
Number of Modules	1 x 128GB
Signal Processing	Buffered
Memory Speed	2400 MHz
Memory Size	128 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2400/PC4-19200
Memory Voltage	1.20 V
Limited Warranty	Lifetime
