Eaton Preassembled BladeUPS - Top Entry 24 kW, 208V ZP222100XXXX000

The Eaton BladeUPS is a revolutionary power quality solution that is scalable and modular. BladeUPS expands power protection from 12 to 60 kW in a single 19-inch rack while reducing energy and cooling costs.

Product Type	Dual Conversion Online UPS
Brand Name	Eaton
Manufacturer	Eaton Corporation
Product Name	Preassembled BladeUPS - Top Entry 24 kW, 208V
Product Line	BladeUPS
Manufacturer Part Number	ZP222100XXXX000
Manufacturer Website Address	http://www.eaton.com/EatonCom/Markets/NorthAmerica
Batteries	80 x Sealed, Maintenance-free Valve-regulated Lead Acid (VRLA) User Replaceable Hot-swappable
Backup/Run Time	0.08 Hour 24 kW Full Load0.22 Hour 12 kW Half Load
Height	81"
Width	24"
Depth	42"
Form Factor	Tower
Weight (Approximate)	994.28 lb
Receptacles	Hard Wire 4-wire 3PH + G
Plug/Connector Type	Hardwired
Interfaces/Ports	2 x RS-232 Serial
Input Voltage Range	180 V AC to 265 V AC208 V AC Nominal
Load Capacity	24 kW
Input Voltage	220 V AC
Output Voltage	208 V AC Nominal120 V AC Nominal180 V AC to 228 V AC
Package Contents	Preassembled BladeUPS - Top Entry 24 kW, 208V 1 x S-Series Rack on a Heavy-duty Shipping Pallet with Unloading Ramp BladeUPS Parallel bar and Wireway 2 x BladeUPS Modules Intelligent Power Software CD BladeUPS Installation and User Manual Rack Hardware Kit Front and Rear Rack Aesthetic Plates
Limited Warranty	1 Year
