KanexPro Multiview 4X1 KVM Switch SW-4X1KVMMV

The KanexPro 4X1 KVM Switch (SW-4X1KVMMV) is an advanced KVM processor for monitoring and controlling up to 4 host devices. The processor supports four host devices in 1080p/60hz resolution through a single HDMI output. The Multiview functionality provides real-time control of the four connected host devices while using a single mouse keyboard combo. The KVM Multiview function allows the system to tile four 1080p hosts onto a single 1080p display. This feature is especially useful when combined with a multi-camera NVR/DVR system because it allows the operator to monitor each camera in the best quality possible. The seamless switching mechanism assures there will be nothing missed when switching from one feed to the next. Using the single mouse and keyboard the user can control one of the four host devices at a time while displaying all four on screen at once, simply use the hotkey command to switch between hosts. Useful in a variety of other environments like server rooms, power user workstations, classrooms, front of house control boards, hospitality, and retail loss prevention. Applications: Ideal for use in video surveillance, research and development, factory and production, instructing, movie editing, front of house control boards, hospitality, restaurants, bars, and any place where there is a need to manage more than one computer, server, or DVR with a single mouse and keyboard combination.

USB	Yes
HDMI	Yes
Number of HDMI Ports	5
Number of USB Ports	8
Product Type	KVM Switchbox
Manufacturer Part Number	SW-4X1KVMMV
Manufacturer Website Address	http://www.kanexpro.com
Manufacturer	KanexPro
Product Name	Multiview 4X1 KVM Switch
Product Line	MultiView
Brand Name	KanexPro
Weight (Approximate)	2.43 lb
Height	1.6"
Width	4.2"
Depth	7.3"
Input Voltage Range	100V AC to 240V AC
Maximum Operating Distance	229.66 ft
Number of Computers Supported	4
Number of Local Users Supported	1
Limited Warranty	3 Year
