High-Performance AV Matrix - Switches 6 [email protected]
(4:4:4), HDR, HDMI, HDCP (2.2/1.4)-compliant signals to 6 [email protected]
(4:4:4), HDR, HDMI, HDCP (2.2/1.4)-compliant outputs at up to 18G data rate. Featuring Kramer re-Klocking™ and Equalization Technology that rebuilds the digital signal to travel longer distances. Note: For optimum range and performance, use recommended Kramer cables. HDMI Support - Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels as specified in HDMI 2.0. Independent Audio Routing - Any embedded digital audio input can be routed to any digital output, in addition to ARC sources, to produce an equivalent 12x9 audio matrix (6 embedded digital inputs + 6 ARC inputs and 6 digital outputs + 3 ARC outputs). Easy Step-In Collaboration Function - When used with a Kramer Step-In enabled switcher, just plug in your device and press the Step-In button. Your device becomes the active signal on the main display. EDID Management - Individual EDID management per input. Captures and stores the EDID from a display device. Flexible Content Protection - Selectable HDCP per input. Quick Access to Common Configurations - Save up to 16 preset configurations. Smart Switching - Active source & acceptor detection. Automatic input selection based on priority selection or last connected input. Embedded Pattern Generator - With selectable patterns. Convenient Unit Control and Configuration Options - Local control via front panel switching, memory, lock and EDID buttons, and Input/Output LED display. Distance control via user-friendly embedded web pages via the Ethernet, Protocol 3000 API, and RS-232 serial commands transmitted by a PC, touch screen system or other serial controller. Cost-Effective Maintenance - Input selection indicators facilitate easy local maintenance and troubleshooting. Firmware upgrade via Ethernet or mini USB. Easy Installation - 19" enclosure for rack mounting in a 1U rack space with included rack ears and universal 100-240V AC power supply.
