Sans Digital MobileSTOR - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Black) KT-MS12X6+B MS12X6+B

Sans Digital MobileSTOR - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Black) KT-MS12X6+B MS12X6+B
Price $1,205.92
Manufacturer: Sans Digital
Mfg Number: KT-MS12X6+B
SKU:
Model: MS12X6+B
Condition: New
UPC: 739410734884
Accessories
Description
The MobileSTOR MS12X6+B series is a 12 bay mini-SAS SAS expander tower comprised of the same engines as the AccuSTOR / EliteSTOR enterprise level rackmount storage. Utilizing the same engine structure as the enterprise level rackmounts, the MobileSTOR utilize SAS expander technology, and provides up to 24 Gb/s or 2400MB/s of data bandwidth to fulfill the most demanding application. The MS12X6+B supports both SATA or SAS 6Gb/s solid state drives and hard drives and is backward compatible to 3Gbps SAS & SATA SSD and HDDs. By utilizing the latest SAS expander technology, the MS12X6+B supports up to 12 SAS or SATA drives using only one mini-SAS cable. A built-in SAS expansion port enables the system to connect up to 5 units or 60 HDD drives daisy-chained together. With a high performance RAID controller card such as Areca, ATTO, Highpoint and LSI 6G RAID controller, the MS12X6+B is capable of delivering over 1500MB/s in read/write performance with RAID controller, doubling the existing 3G SAS expander bandwidth. Drives status information is provided by the LED. All necessary hardware comes standard including mini-SAS cable, hot-swappable cooling fan, and hard drives tray modules. The MS12X6+B is an ideal storage expansion solution for servers or high performance video editing workstations.
Specifications
Product TypeDAS Array
Brand NameSans Digital
ManufacturerSans Digital
Product ModelMS12X6+B
Product NameMobileSTOR MS12X6+B - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Black)
Product LineMobileSTOR
Manufacturer Part NumberKT-MS12X6+B
Manufacturer Website Addresshttp://www.sansdigital.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Package Contents
  • MobileSTOR MS12X6+B - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Black)
  • 8 x Removable Tray Modules
  • 1 x Power Cord
  • 1 x Mini-SAS Cable
  • 1 x Quick Installation Manual & CD
RAID SupportedYes
Controller Type6Gb/s SASSerial ATA/600
Number of Total Expansion Bays12
Number of 3.5" Bays12
Number of 5.25" BaysNo
Number of 2.5" BaysNo
Number of 2.5"/3.5" BaysNo
Total Hard Drive Capacity Supported48 TB
Total Solid State Drive Capacity Supported48 TB
Number of Hard Drives Supported12
Number of Hard Drives InstalledNo
Number of Solid State Drive Supported12
Number of Solid State Drive InstalledNo
Height19.5"
Width8"
Depth13"
Form FactorTower
Weight (Approximate)28 lb
Limited Warranty1 Year
Host InterfaceMini-SAS
