Server Technology PRO2 36-Outlet PDU C2W36CE-YCMFA900

The Server Technology PRO2 Switched Rack PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched "Master" PDU can be connected to as many as three PRO2 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Product Type	PDU
Product Series	PRO2
Brand Name	Server Technology
Manufacturer	Server Technology, Inc
Product Name	PRO2 36-Outlet PDU
Manufacturer Part Number	C2W36CE-YCMFA900
Manufacturer Website Address	http://www.servertech.com
Environmentally Friendly	Yes
Environmental Certification	RoHSWEEEcTUVus
Network (RJ-45)	Yes
Height	70"
Width	2.2"
Depth	2.5"
Rack Height	0U
Form Factor	Rack-mountable
Weight (Approximate)	22.05 lb
Power Rating	8.60 kVA
Input Current	30 A
Input Voltage	120 V AC208 V AC
Output Voltage	120 V AC208 V AC
Input Receptacles	NEMA L15-20P
Output Receptacles	36 x IEC 60320 C13
Protection Type	Circuit Protection
Management	HTTP HTTPS SSL v3/TLSv1 SSHv2 Telnet SNMPv2c and v3 (GET, SET, Traps) IPv4 IPv6 LDAPv3/LDAPS TACACS+ RADIUS FTP/SFTP
Limited Warranty	2 Year
