Supermicro A+ Server AS -1013S-MTR 1013S-MTR

Optimized for high-performance computing and scalability, Supermicro's AMD EPYC™ 7000-series based dual-socket systems support up to 64 cores or 128 threads in a high-density 1U form-factor. With industry-leading memory bandwidth supporting up to 4TB of the latest DDR4 memory on 16 memory channels, up to 10 NVMe/SATA3 drive bays, complete SoC with fully integrated high-speed I/O supporting 128 lanes of PCI-E 3.0, and Infinity Fabric coherent interconnect between the two processors. These systems are ideal for virtualization, web, cloud computing and HPC applications.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	1013S-MTR
Product Name	A+ Server 1013S-MTR
Product Line	A+ Server
Manufacturer Part Number	AS -1013S-MTR
Manufacturer Website Address	http://www.supermicro.com
64-bit Processing	Yes
Number of Processors Supported	1
Processor Socket	Socket SP3
Processor Supported	EPYC
Chipset Manufacturer	AMD
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500
Number of SATA Interfaces	4
Total Number of USB Ports	9
Number of USB 3.0 Ports	5
Number of Total Memory Slots	8
Memory Standard	DDR4-2666/PC4-21300
Memory Technology	DDR4 SDRAM
Maximum Memory Supported	1 TB
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Bays	4
Number of 3.5" Bays	4
Number of Total Expansion Slots	1
Number of PCI Express x16 Slots	1
Maximum Power Supply Wattage	400 W
Input Voltage	120 V AC 230 V AC
Height	1.7"
Width	17.2"
Depth	19.9"
Rack Height	1U
Form Factor	Rack-mountable
Weight (Approximate)	20.06 lb
Controller Type	Serial ATA/600
