Supermicro SuperServer SYS-6017R-TDLF 6017R-TDLF

Designed for optimal performance, the dual-processor SuperServers support the QPI (8.0GT/s) format Xeon® processor E5-2600 or E5-2600 v2 family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6017R-TDLF
Product Name	SuperServer 6017R-TDLF
Product Line	SuperServer
Manufacturer Part Number	SYS-6017R-TDLF
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6017R-TDLF 1 x Super X9DRD-LF Motherboard 1 x 1U Chassis 1 x 2x 3.5" hard drive backplane designed for CSE-813LT-R500CB-BULK 1 x 4 pin to 4 pin power extension .HDD to RA,40cm. 20AWG 2 x 43CM SATA ROUND S-RA PBF 26AWG 2 x 1U Passive CPU Heat Sink for X9 Generation Motherboards w/ Narrow ILM 1 x 1U 350W MULTI OUTPUT 80PLUS GOLD PWS 2 x 97Lx94Wx37H mm 5K RPM SC813 Rev. M Chassis Middle Cooling Blower 2 x Black gen 5.5 hot-swap 3.5" HDD tray 1 x Outer rail, quick-release type 1 x Inner rail, front, quick-release type
Chipset Manufacturer	Intel
Chipset Model	C602
Number of Processors Supported	2
QuickPath Interconnect Supported	Yes
Processor Socket	Socket R LGA-2011
Processor Supported	Xeon
Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200eW
Number of SATA Interfaces	2
VGA	Yes
Total Number of USB Ports	4
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit EthernetFast Ethernet
Number of Total Expansion Bays	2
Number of 3.5" Bays	2
Number of Total Expansion Slots	1
Number of PCI Express x16 Slots	1
Memory Standard	DDR3-1866/PC3-15000
Memory Technology	DDR3 SDRAM
Maximum Memory	512 GB
Height	1.7"
Width	17.2"
Depth	25.6"
Color	Black
Rack Height	1U
Form Factor	Rack-mountable
Limited Warranty	3 Year
