Supermicro Processor Blade (Black) SBI-4129P-T3N

The innovative and feature-rich SuperBlade® enhances system computing density by housing multiple blade servers in a single enclosure. Applying Supermicro's application-optimized engineering philosophy and leveraging years of rackmount server design experience, SuperBlade® modules deliver true server functionality and boast simplified access and maintenance with front-loading nodes. Each node includes up to four 28-Core Intel® Xeon® Scalable Processors with 3TB DDR4 2666MHz in 48 DIMM slots, 205W per socket, NVMe/SAS3 HDD support, optional 100G EDR InfiniBand/Intel Omni-Path or 10G mezzanine HCA, optional PCI-E 3.0 expansion card, support for up to 8 NVMe or 4 SATA3/SAS3 hard drives, and 100-240VAC redundant Titanium Level high-efficiency (96%), N+1 power supplies. Each blade server fits into existing Supermicro blade enclosures, thus protecting initial investments and offering smooth product upgrades and migrations.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	SBI-4129P-T3N
Product Name	Processor Blade SBI-4129P-T3N (Black)
Product Line	SuperBlade
Manufacturer Part Number	SBI-4129P-T3N
Manufacturer Website Address	http://www.supermicro.com
Environmentally Friendly	Yes
Environmental Certification	RoHS
Package Contents	Processor Blade SBI-4129P-T3N (Black) 1 x Super B11DPT-P Motherboard 1 x 4U 10 SuperBlade Processor Blade chassis 1 x Single SATA3 hard drive supporting expansion card for B11DPT 1 x Front Control Board with KVM connector for B11DPT, RoHS 1 x SATA,INT,ROUND,ST-RA,55CM,30AWG 2 x Black 2.5" NVMe Hard Drive Tray, orange button 1 x Air shroud set for 4U 10-Blade
64-bit Processing	Yes
Number of Processors Supported	2
Processor Socket	Socket P LGA-3647
Processor Supported	Xeon
Chipset Manufacturer	Intel
Chipset Model	C622
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500
Number of Internal 2.5" Bays	2
Number of Total Expansion Bays	3
Number of Total Memory Slots	16
Memory Standard	DDR4-2666/PC4-21300
Memory Technology	DDR4 SDRAM
Maximum Memory Supported	2 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	10 Gigabit Ethernet
Product Color	Black
Height	6.5"
Width	1.8"
Depth	23.5"
Form Factor	Blade
Weight (Approximate)	9.50 lb
Limited Warranty	1 Year
