Supermicro SuperServer (Black) SYS-1018GR-T 1018GR-T

Supermicro's NVIDIA Tesla supported SuperServers® establish the company as the true global leader in High-Performance, Enterprise-Class SuperComputing and GreenIT. Generating massively parallel processing power and unrivaled networking flexibility with PCI-E 3.0 expansion slots, 1G or 10G Ethernet, and FDR InfiniBand ports, these systems deliver the highest quality with extreme optimization for the most computationally-intensive applications.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	1018GR-T
Product Name	SuperServer 1018GR-T (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-1018GR-T
Manufacturer Website Address	http://www.supermicro.com
Environmentally Friendly	Yes
Environmental Certification	RoHS
Package Contents	SuperServer 1018GR-T (Black) 1 x Super X10SRG-F Motherboard 1 x 1U Black SC118GTQ Chassis 1 x 6-port 1U TQ (W/ AMI 9072) backplane, support up to 6x 2.5-inch SAS/SATA HDD/SSD 2 x CBL,SGPIO,2X4F TO 2X4F,P2.54,ROUND CABLE,61.5CM,28AWG 2 x SATA,INT,ROUND,ST-ST,70CM,30AWG 4 x SATA,INT,ROUND,ST-ST,55CM,30AWG 1 x 8 pin to two 6+2 pin 12V GPU power cable, 30 cm 16/20 AWG, 10A/pin(16AWG), 6A/pin(20AWG), -25~85C, RoHS/REACH 1 x SYS-1018GR-T 1U UP Qucik Reference Guide,HF,RoHS/REACH 1 x RSC-R1U-E16R 1 x 1U RHS Riser Card with 1 PCI-E x16 for UP GPU MB 1 x 1U LHS Riser Card with one PCI-E x16 for UP GPU MBs 1 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 1 x 1400W redundant digital power supply
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Processors Supported	1
Processor Socket	Socket R3 LGA-2011
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	6
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1400 W
Input Voltage	120 V AC230 V AC
Number of Internal 2.5" Bays	6
Number of Total Expansion Bays	6
Number of Total Expansion Slots	3
Number of PCI Express x8 Slots	1
Number of PCI Express x16 Slots	2
Number of Total Memory Slots	8
Memory Standard	DDR4-2400/PC4-19200
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Height	1.7"
Width	17.2"
Depth	28.5"
Color	Black
Rack Height	1U
Form Factor	Rack-mountable
Weight (Approximate)	28 lb
Limited Warranty	3 Year
