Supermicro SuperServer (Black) SYS-6028TP-HC1R-SIOM 6028TP-HC1R-SIOM

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Number of SAS Interfaces	3
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Controller Type	12Gb/s SAS Serial ATA/600
RAID Supported	Yes
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Product Type	Barebone System
Manufacturer Part Number	SYS-6028TP-HC1R-SIOM
Manufacturer Website Address	http://www.supermicro.com
Manufacturer	Supermicro Computer, Inc
Product Model	6028TP-HC1R-SIOM
Product Name	SuperServer 6028TP-HC1R-SIOM (Black)
Product Line	SuperServer
Brand Name	Supermicro
Number of Total Expansion Bays	3
Number of 3.5" Bays	3
Number of Total Expansion Slots	2
Number of PCI Express x8 Slots	1
Number of PCI Express x16 Slots	1
Maximum Memory Supported	2 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2400/PC4-19200
Number of Total Memory Slots	16
Package Contents	SuperServer 6028TP-HC1R-SIOM (Black) 4x Super X10DRT-PS Motherboard 1 x 2U Chassis 4 x TwinPo 217HQ+/827HQ+ X10 plastic air shroud,RoHS/REACH 1 x 12-port 2U TwinPro^2 SAS3 CSE-827HQ (3 drives per node) backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD 4 x LSI 3108, SAS 12Gbps (x6 internal) 2 x PWCD,US,IEC60320 C14 TO C13,3FT,14AWG 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 4 x 1U RHS TwinPro Riser card with one PCI-E x16 slot 4 x RSC-P-6 (1U LHS TwinPro RSC with 1 PCI-Ex16),RoHS 4 x 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers 4 x 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 2 x AC-DC 2000W, Titanium Level, Redundancy, 1U, PMBus 1.2, +12V/+5Vsb, 360x76x40mm,HF,RoHS/REACH 4 x TwinPro 217HQ+/827HQ+ X10 plastic air shroud or TwinPro 217HQ+/827HQ+ X10 mylay air shroud 2 x 2000W Redundant Titanium Level Power Supplies
Environmentally Friendly	Yes
Environmental Certification	RoHS
Ethernet Technology	Ethernet
Weight (Approximate)	72.09 lb
Form Factor	Rack-mountable
Rack Height	2U
Height	3.5"
Width	17.3"
Depth	30.5"
Product Color	Black
Input Voltage	120 V AC 230 V AC
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	2000 W
Limited Warranty	3 Year
Processor Supported	Xeon
Processor Socket	Socket R3 LGA-2011
64-bit Processing	Yes
Number of Nodes	4
Number of Processors Supported	2
Chipset Manufacturer	Intel
Chipset Model	C612
