Tripp Lite MTP/MPO Singlemode Patch Cable (F/F), Yellow, 1 m N390-01M-12-AP

Tripp Lite MTP/MPO Singlemode Patch Cable (F/F), Yellow, 1 m N390-01M-12-AP
Price $191.74
Manufacturer: Tripp Lite
Mfg Number: N390-01M-12-AP
Condition: New
UPC: 037332205360
The N390-01M-12-AP MTP/MPO Singlemode Patch Cable (F/F) supports 40/100 Gb Ethernet speeds and is designed for QSFP+ applications in enterprise installations in wiring closets, telecom rooms and data centers. With two female MTP/MPO connectors, this singlemode fiber optic cable with plenum-rated jacket is recommended for connecting switches, hubs, routers and other high-speed network components in ceilings, walls and ducts. The 12-fiber MTP/MPO connectors are about the same size as SC connectors, but are 12 times denser, freeing up rack space for other cables. The APC connectors are angled to prevent infrared light entering the fiber from bouncing back into the laser. The N390-01M-12-AP is tested for low insertion loss and back reflection on every connector and attenuation loss that meets or exceeds current standards. The N390-01M-12-AP is colored yellow for instant identification in a crowded switch or patch panel as a singlemode cable. Push/pull tab connectors are easily accessible in high-density data center environments and make the plug-and-play cable easy to install and remove with one hand.
Product TypeNetwork Cable
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelN390-01M-12-AP
Product NameN390-01M-12-AP MTP/MPO Singlemode Patch Cable (F/F), Yellow, 1 m
Manufacturer Part NumberN390-01M-12-AP
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
Cable CharacteristicPatch Cable
Connector on First End1 x MTP/MPO Female Network
Connector on Second End1 x MTP/MPO Female Network
Cable TypeFiber Optic
Core/Cladding Diameter8.3/125 µm
Fiber Optic ModeSingle-mode
FeaturesAngled Connector
Data Transfer Rate12.50 GB/s
Device SupportedNetwork DeviceSwitchHubRouterPatch Panel
Cable Length3.28 ft
Limited WarrantyLifetime
