Tripp Lite Metered 19-Outlets PDU PDUMH30HVAT

PDUMH30HVAT Metered ATS / Auto-Transfer Switch offers 208/240V 30A dual-input power distribution and visual current metering in a 2U horizontal rackmount installation format. Set of two NEMA L6-30P line cords enable separate primary and secondary input connections. Includes 19 built-in outputs (16 C13, 2 C19 & 1 L6-30R). Digital current metering with push-button display control tracks output power consumption in 4 segments: Bank 1 (9 upper C13 & C19 outlets), Bank 2 (9 lower C13 & C19 outlets), L6-30R (single outlet) and total PDU output. Supports 2U installation in 2 or 4 post racks, with additional support for wall-mount and under-counter placement.

Product Type	PDU
Product Series	Metered
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	PDUMH30HVAT
Product Name	Metered PDUMH30HVAT 19-Outlets PDU
Manufacturer Part Number	PDUMH30HVAT
Manufacturer Website Address	http://www.tripplite.com
Package Contents	Metered PDUMH30HVAT 19-Outlets PDU Rackmount Installation Brackets Installable Plug-retention Shelves Cable Ties
Number of Cord/Cable	2
Height	3.5"
Width	17.5"
Depth	12.5"
Rack Height	2U
Form Factor	Horizontal Rackmount
Weight (Approximate)	13.80 lb
Input Voltage	208 V AC240 V AC
Output Voltage	208 V AC240 V AC
Input Receptacles	2 x NEMA L6-30P
Output Receptacles	1 x NEMA L6-30R2 x IEC 60320 C1916 x IEC 60320 C13
Limited Warranty	2 Year
