Tripp Lite 20-Outlet PDU PDUMNV20HV2LX

Tripp Lite 20-Outlet PDU PDUMNV20HV2LX
Price $412.85
Manufacturer: Tripp Lite
Mfg Number: PDUMNV20HV2LX
Condition: New
UPC: 037332205346
The PDUMNV20HV2LX 3.3/3.7kW Single-Phase Monitored PDU provides real-time remote monitoring of voltage, frequency and load levels via built-in network connection. By reducing the frequency of on-site visits, these advanced remote capabilities can save you money and reduce downtime.Recommended for your IT or industrial application, the 0U PDU features 20 outlets (18 C13 and 2 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. The C20 inlet is compatible with a wide variety of user-supplied power cords for connecting to an AC source, generator or protected UPS. A detachable 10-foot cord with NEMA L6-20P plug is included.The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.A digital ammeter allows you to monitor the total connected load in real time to ensure it remains well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets.
Product TypePDU
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelPDUMNV20HV2LX
Product NamePDUMNV20HV2LX 20-Outlet PDU
Manufacturer Part NumberPDUMNV20HV2LX
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
TAA CompliantYes
Package Contents
  • PDUMNV20HV2LX 20-Outlet PDU
  • Built-in LX Platform Interface
  • Detachable NEMA L6-20P to C19 Power Cord, 10 ft.
  • Configuration Cable
  • 20 x Plug-lock Inserts
  • Rack-mounting hardware
  • Mounting Bracket Accessory
  • Owner's Manual
Mounting OrientationVertical
Rack Height0U
Form FactorRack-mountable
Weight (Approximate)6.50 lb
Power Rating (Watt)3700 W
Input Current20 A
Input Voltage230 V AC
Output Voltage208 V AC230 V AC
Input ReceptaclesNEMA L6-20PIEC 60320 C20
Output Receptacles2 x IEC 60320 C1918 x IEC 60320 C13
  • IPv4
  • IPv6
  • HTTP
  • SMTP
  • SNMPv1
  • SNMPv2
  • SNMPv3
  • telnet
  • SSH
  • FTP
  • DHCP
  • NTP
Limited Warranty2 Year
