Tripp Lite SmartRack Rack Cabinet SRW12USNEMA

Tripp Lite SmartRack Rack Cabinet SRW12USNEMA
Price $815.67
Manufacturer: Tripp Lite
Mfg Number: SRW12USNEMA
SKU:
Condition: New
UPC: 037332168016
Accessories
Description
The SRW12USNEMA 12U Industrial Wall-Mount Rack Enclosure Cabinet is ideal for customers who need to protect valuable equipment in harsh working environments that would overwhelm a typical rack. It is designed to integrate wall-mounting, easy equipment access, and cable management in IT network applications with limited floor space. The enclosure has a NEMA 12 protection rating, which is equivalent to IP54. That means it can protect your equipment from falling dirt, dust, drips, splashes and accidental contact with personnel. The front and side panels have ventilating louvers instead of open mesh. They also have a sealing gasket around the door frames. On the front door there is a built-in dust filter. The filter is removable and can be replaced with standard furnace filters - they're simple, inexpensive and effective. To compensate for the added air resistance of the filters, there are 4 large, high performance intake fans in the front door. The fans pull air through the enclosure, from front to side. Since the doors and top are sealed, cable access is provided through 4 self sealing cable ports - 4 in the rear side. They allow cables to pass through, but they block the area around the cables maintaining the NEMA 12 protection. Adjustable rack rails with square mounting holes accommodate up to 12U of standard 19" rackmount equipment. Supports up to 140 lbs of equipment. A sturdy hinge between the cabinet and the wall-mount bracket allows the cabinet to swing away from the wall for easy access to equipment and cabling.
Specifications
Product TypeRack Cabinet
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelSRW12USNEMA
Product NameSmartRack SRW12USNEMA Rack Cabinet
Product LineSmartRack
Manufacturer Part NumberSRW12USNEMA
Manufacturer Website Addresshttp://www.tripplite.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Assembly RequiredNo
Package Contents
  • SmartRack SRW12USNEMA Rack Cabinet
  • 20 x M6 Cagenuts
  • 20 x M6 Screws
  • 20 x Washers
  • 2 x Keys
  • 1 x Removable/Replaceable Dust Filter
  • Owner's Manual
Height25"
Width23.6"
Depth21.6"
ColorBlack
Rack Width19"
Rack Height12U
Form FactorWall Mountable
Weight (Approximate)60 lb
Limited Warranty5 Year
