Tripp Lite SmartOnline 80kVA Tower UPS SV80KM4P0B

The SV80KM4P0B SmartOnline® SV Series 80kVA 3-Phase On-Line Double-Conversion UPS System delivers true scalability and offers the highest level of secure, uninterrupted power protection. Featuring a modular, scalable design with high-efficiency voltage and frequency independent (VFI) operation, this on-line UPS system is ideal for protecting a variety of critical IT systems. The SV80KM4P0B includes pre-installed input, bypass and output breakers, as well as a static transfer switch (STS) and four 20kVA SV20PM power modules. It comes fully configured for 80kVA total capacity or 60kVA with enhanced N+1 protection. External ±120VDC battery options, such as BP240V370 or EBP240VXXX series battery cabinets, are available from Tripp Lite for extended runtimes. The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. With up to 92% efficiency in standard mode and up to 99% efficiency in optional economy mode, this 80kVA UPS system helps you reduce operating and cooling costs. Automatic and manual bypass options keep connected equipment operational during routine maintenance or critical power module failure. Front-panel display offers full UPS condition and status reporting. Features 80kVA 72kW 3-Phase Medium-Chassis UPS System Supports 208/120V or 220/127V AC 50/60Hz Wye 4-wire plus Earth hardwire input and output wiring Dual hardwire input design enables operation from up to 2 power sources Network-grade sine-wave AC output with 1% output voltage regulation and less than 1% output total harmonic distortion Tested to UL 1778 (U.S.), CSA (Canada) and NOM (Mexico) standards High 0.9 power factor for maximum power to the connected load Pre-Installed WEBCARDLX Network Interface Allows full remote access for power monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH Supports 10/100 Mbps auto-sensing for communication with an Ethernet network Optional EnviroSense2 sensors (sold separately) enable site monitoring of temperature, humidity and contact-closure status No Java required Modular, Scalable Design for Maximum Flexibility Modular configuration with hot-swappable power modules, and fast maintenance with zero downtime Comes fully configured for 80kVA total capacity or 60kVA with N+1 fault tolerance Supports external ±120VDC battery options for extended runtimes Optional Economy Mode Up to 99% efficient in optional economy mode to lower operating and cooling costs Wide Input/Narrow Output Voltage Operating Range Enables full continuous online operation during brownouts as low as 121V and overvoltages up to 253V Regulates output voltage within 1% of the selected nominal output voltage in on-line double-conversion mode Advanced IGBT Inverter with Digital Signal Processor (DSP) Technology Provides for less than 2% input total harmonic distortion (THDi) to support 1:1 generator sizing and prevent the need to oversize generator systems relative to UPS capacity Automatic and Manual Bypass Options Keep connected equipment operational during routine maintenance or critical power module failure

Product Type	Dual Conversion Online UPS
Product Series	SV
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	SV80KM4P0B
Product Name	SmartOnline SV80KM4P0B 80kVA Tower UPS
Product Line	SmartOnline
Manufacturer Part Number	SV80KM4P0B
Manufacturer Website Address	http://www.tripplite.com
Environmentally Friendly	Yes
Environmental Certification	RoHS
Package Contents	SmartOnline SV80KM4P0B 80kVA Tower UPS Pre-installed WEBCARDLX Network Interface 4 x SV20PM 20kVA Power Module (Shipped Separately) Owner's Manual DB9 Cable
AVR	Yes
Receptacles	Hardwire (3P + N + E)
Plug/Connector Type	Hardwired
Typical Battery Recharge Time	4.60 Hour
Height	79.1"
Width	23.6"
Depth	43.3"
Form Factor	Tower
Load Capacity	80 kVA/72 kW
Input Voltage	120 V AC127 V AC208 V AC220 V AC
Output Voltage	120 V AC208 V AC127 V AC220 V AC
Network Management	SNMP/HTTP Remote Monitoring
Limited Warranty	1 Year
