Intel Server System R2308GL4DS9

Incredible Server Performance and Flexibility in an Energy Efficient Custom DesignThe Intel® Server System R2300GL family takes full advantage of the new Intel® Xeon® processor E5-2600 product family capabilities with the Intel® Server Board S2600GL family. The Intel Server System R2300GL family features an energy efficient spread core design and maximum (512 GB) memory capacity with up to 16 DIMMS, S2600GL-based rack-optimized server systems deliver unmatched performance, I/O capacity, and flexibility in an expansive family of 1U and 2U systems for the most demanding enterprise data center, cloud, or high performance computing (HPC) environments.

Product Type	Barebone System
Brand Name	Intel
Manufacturer	Intel Corporation
Product Model	R2308GL4DS9
Product Name	Server System R2308GL4DS9
Product Line	Server System
Manufacturer Part Number	R2308GL4DS9
Manufacturer Website Address	http://www.intel.com
64-bit Processing	Yes
Number of Processors Supported	2
Processor Socket	Socket R LGA-2011
Processor Supported	Xeon
Graphics Controller Manufacturer	Intel
Number of SATA Interfaces	10
Number of SAS Interfaces	No
Total Number of USB Ports	6
Number of Power Supplies Installed	1
Maximum Power Supply Wattage	460 W
Number of Total Memory Slots	16
Memory Standard	DDR3-1600/PC3-12800
Memory Technology	DDR3 SDRAM
Maximum Memory	512 GB
RAID Supported	Yes
Controller Type	Serial ATA
Ethernet Technology	Gigabit Ethernet
Number of 3.5" Bays	8
Number of Total Expansion Slots	6
Number of PCI Express x8 Slots	6
Height	3.4"
Width	16.9"
Depth	28"
Rack Height	2U
Form Factor	Rack-mountable
