Raritan 8-Outlets PDU PX3-5180R-F5

Monitored - NEMA L6-20P (2P3W) - 8 x IEC 60320 C13 - 230 V AC - Network (RJ-45) - 1U - Horizontal - Rack-mountable

Network (RJ-45)	Yes
Product Type	PDU
Manufacturer Part Number	PX3-5180R-F5
Manufacturer Website Address	http://www.legrand.us
Manufacturer	Legrand Group
Product Model	PX3-5180R-F5
Product Name	PX3-5180R-F5 8-Outlets PDU
Product Series	PX3
Brand Name	Raritan
Management	HTML JSON-RPC SSH Telnet MODBUS/TCP HTTP(s) RS-232 (Serial) Power IQ SNMP version v2/v3 SMTP JSON-RPC Modbus over TCP
Environmentally Friendly	Yes
Environmental Certification	RoHS
Weight (Approximate)	6.83 lb
Mount Type	Rack-mountable
Rack Height	1U
Height	1.7"
Width	17.3"
Depth	7.2"
Mounting Orientation	Horizontal
Input Voltage	230 V AC
Output Voltage	208 V AC
Input Current	20 A
Power Rating (VA)	3700 VA
Protection Type	Overload Protection Double Pole Overcurrent Protection Splash Proof
Plug/Connector Type	NEMA L6-20P (2P3W)
Receptacle Type	IEC 60320 C13
PDU Type	Monitored
Receptacle Detail	8 x IEC 60320 C13
Plug/Connector Detail	1 x NEMA L6-20P (2P3W)
Limited Warranty	2 Year
