Tyan Tank Barebone System B5380T26V8H-RS TA26 (B5380)

The Tank TA26 (B5380) provides high-density storage for departmental/NAS 2U rackmount applications. Supports dual Intel Xeon processors, 8 FBDIMM memory sockets, PCI-E and PCI-X expansion slots, 6 SATA-II hot-swap drive bays, built-in 650W PFC power supply and much more.

Product Type	Barebone System
Product Series	TA26
Brand Name	Tyan
Manufacturer	Tyan Computer Corp
Product Model	TA26 (B5380)
Product Name	Tank TA26 (B5380) Barebone System
Product Line	Tank
Manufacturer Part Number	B5380T26V8H-RS
Manufacturer Website Address	http://www.tyan.com
Front Side Bus	1333 MHz1066 MHz
Chipset Manufacturer	Intel
Chipset Model	5000P
Number of Processors Supported	2
Processor Socket	Socket J LGA-771
Processor Supported	Xeon
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Number of External 5.25" Bays	1
Number of Total Expansion Bays	9
Number of 3.5" Bays	8
Number of Total Expansion Slots	5
Number of PCI Express x16 Slots	2
Graphics Controller Manufacturer	ATI
Graphics Controller Model	ES1000
Graphics Memory Capacity	32 MB
Graphics Controller Interface	PCI
RAID Supported	Yes
Controller Type	Serial ATA/300
Ethernet Technology	Gigabit Ethernet
VGA	Yes
Total Number of USB Ports	8
Memory Standard	DDR2-667/PC2-5300
Memory Technology	DDR2 SDRAM
Maximum Memory	16 GB
Height	3.5"
Width	17"
Depth	26"
Rack Height	2U
Form Factor	Rack-mountable
Limited Warranty	3 Year
