Tyan Barebone System B7016G24W4H GT24 (B7016)

The hottest 1U GT24 (B7016) Barebone System features Intel Xeon processors within providing greatest computing capability to HPC and virtualization applications. TYAN GT24-B7016 supports up to 144GB DDR3 RDIMM memory, (4) 3.5" hot-swap SATA-II HDDs, (3) GbE, (2) full-height PCI-E Gen.2 x8 slots and onboard IPMI with iKVM features. This system is perfectly fit for search engines, virtualization and the most of HPC applications.

Product Type	Barebone System
Product Series	GT24
Brand Name	Tyan
Manufacturer	Tyan Computer Corp
Product Model	GT24 (B7016)
Product Name	GT24 (B7016) Barebone System
Manufacturer Part Number	B7016G24W4H
Manufacturer Website Address	http://www.tyan.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS80 Plus
Package Contents	GT24 (B7016) Barebone System 1 x Quick Reference Guide 1 x MB User Manual 1 x BB User Manual 1 x TYAN installation CD 2 x CHSK-0380, LGA1366 CPU Heatsinks for S7016 (proprietary) 1 x CRAL-0031, Sliding Rail Kit for KGT24 1 x CEAR-0050, Mounting Ear Kit for GT20/ GT24 1 x HDD screw pack 1 x CCBL-0310, US type Power Cord 1 x CCBL-0300, EU type Power Cord
Chipset Manufacturer	Intel
Chipset Model	5520
Number of Processors Supported	2
Processor Socket	Socket B LGA-1366
Processor Supported	Xeon
Graphics Controller Model	ServerEngines Pilot2
Optical Drive Type	DVD-Reader
Optical Media Supported	DVD-ROM
RAID Supported	Yes
Controller Type	Serial ATA/300Serial Attached SCSI (SAS)
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Bays	4
Number of 3.5" Bays	4
Number of Total Expansion Slots	2
Number of PCI Express x16 Slots	1
VGA	Yes
Total Number of USB Ports	4
Memory Standard	DDR3-1333/PC3-10600
Memory Technology	DDR3 SDRAM
Maximum Memory	144 GB
Height	1.7"
Width	17.2"
Depth	25.4"
Rack Height	1U
Form Factor	Rack-mountable
Weight (Approximate)	35.27 lb
Limited Warranty	3 Year
