Tyan TN68 (B4989-SI) Barebone System B4989T68W8HR-SI

nVIDIA - Socket F (1207) - Opteron (Dual-core), Opteron (Quad-core) - 256GB Memory Support - DVD-Reader (DVD-ROM) - Gigabit Ethernet, Fast Ethernet - 2U Rack

Product Type	Barebone System
Product Series	TN68
Brand Name	Tyan
Manufacturer	Tyan Computer Corp
Product Model	B4989T68W8HR-SI
Product Name	TN68 (B4989-SI) Barebone System
Manufacturer Part Number	B4989T68W8HR-SI
Manufacturer Website Address	http://www.tyan.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS80 Plus
Package Contents	TN68 (B4989-SI) Barebone System 1 x TN68B4989 Barebone 1 x MB User's Manual 1 x BB User's Manual 1 x TYAN Installation CD 4 x CHSK-0310, LGA 1207 pin CPU Heatsink 1 x CRAL-0120, Sliding Rail Kit for TN68 1 x CEAR-0130, Mounting Ear Kit 1 x M1003-ID-RS, Front Panel Board 1 x M1029, 3-port Power Backplane 1 x HDD Screw Pack 3 x CCBL-0310, US type Power Cords 3 x CCBL-0300, EU type Power Cords
Number of External 5.25" Bays	1
Number of Total Expansion Bays	9
Number of Total Expansion Slots	6
Number of PCI Express x16 Slots	2
Chipset Manufacturer	NVIDIA
Number of Processors Supported	4
Processor Socket	Socket F LGA-1207
Processor Supported	Opteron
Graphics Controller Manufacturer	XGI
Graphics Controller Model	Z9s
Graphics Memory Capacity	32 MB
Optical Drive Type	DVD-Reader
Optical Media Supported	DVD-ROM
RAID Supported	Yes
Controller Type	Serial Attached SCSI (SAS)
Ethernet Technology	Gigabit Ethernet
VGA	Yes
Total Number of USB Ports	4
Memory Standard	DDR2-800/PC2-6400
Memory Technology	DDR2 SDRAM
Maximum Memory	256 GB
Height	3.4"
Width	16.9"
Depth	26.8"
Rack Height	2U
Form Factor	Rack-mountable
Weight (Approximate)	63.93 lb
Limited Warranty	3 Year
