Supermicro SuperServer (Black) SYS-2029GP-TR 2029GP-TR

Supermicro SuperServer (Black) SYS-2029GP-TR 2029GP-TR
Price $3,588.88
Manufacturer: Supermicro
Mfg Number: SYS-2029GP-TR
Model: 2029GP-TR
Condition: New
Intel C621 Chip - 2 TB DDR4 SDRAM DDR4-2666/PC4-21300 Maximum RAM Support - 16 Total Memory Slots - Serial ATA/600 RAID Supported Controller - ASPEED AST2500 Graphic(s) - 10 2.5" Bay(s) - 2 SATA Interface(s) - Processor Support (Xeon Gold, Xeon Silver, Xeon Bronze, Xeon Platinum) - Ethernet - 2 USB 3.0 Port(s) - 2 x 2000 W - 3 Year
Number of SATA Interfaces 2
Total Number of USB Ports 2
Number of USB 3.0 Ports 2
Controller Type Serial ATA/600
RAID Supported Yes
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2500
Product Type Barebone System
Manufacturer Part Number SYS-2029GP-TR
Manufacturer Website Address http://www.supermicro.com
Manufacturer Supermicro Computer, Inc
Product Model 2029GP-TR
Product Name SuperServer 2029GP-TR (Black)
Product Line SuperServer
Brand Name Supermicro
Number of Internal 2.5" Bays 10
Number of Total Expansion Bays 10
Number of Total Expansion Slots 7
Number of PCI Express x16 Slots 7
Maximum Memory Supported 2 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-2666/PC4-21300
Number of Total Memory Slots 16
Package Contents
  • SuperServer 2029GP-TR (Black)
  • 1 x Super X11DPG-SN Motherboard
  • 1 x CSE-218GH-R2K03B Chassis
  • 1 x 2U 10-Port Hybrid Backplane Supports 8 x 2.5" SAS3/SATA3 HDD/SSD and 2 x 2.5" SAS3/SATA3/NVMe Storage Device for GPU Platform,HF,RoHS
  • 6 x GPU,2x4F/CPU to 2x4F/CPU,P4.2, 30CM,16AWG, 10A/pin, -40~105C
  • 1 x 8pin CPU 12V to 4pin x 2pcs 280mm,HF,RoHS
  • 2 x OcuLink v 1.0,INT,PCIe NVMe SSD, 37CM,34AWG
  • 1 x 2U Rear Left hand side Active GPU riser card with two PCI-E
  • 1 x 2U Front LHS Active GPU riser card with two PCI-E x16 slots for X11 and later motherboards.,HF,RoHS
  • 1 x RSC-G2FR-A66-O-P Riser Card
  • 1 x RSC-R2UG-E16R-X9 Riser Card
  • 1 x 2U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism
  • 1 x 2U Passive CPU Heat Sink with a Side Air Channel for X11 Purley Platform Equipped with a Narrow Retention Mechanism
  • 2 x 1U 2000W Redundant Power Supply Platinum 73.5mm width.,RoHS/REACH
  • 1 x Rail set, quick/quick, optional for 1U 17.2"W SC815
Environmentally Friendly Yes
Environmental Certification RoHS
Ethernet Technology Ethernet
Weight (Approximate) 39.50 lb
Form Factor Rack-mountable
Rack Height 2U
Height 3.5"
Width 17.2"
Depth 31"
Product Color Black
Input Voltage 120 V AC 230 V AC
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 2000 W
Limited Warranty 3 Year
Processor Supported Xeon Gold Xeon Silver Xeon Bronze Xeon Platinum
Processor Socket Socket P LGA-3647
64-bit Processing Yes
Number of Processors Supported 2
Chipset Manufacturer Intel
Chipset Model C621
